VFT – Valves 65000 psi

MAXIMATOR valves of the 65V series have a cold-machined stainless steel body. Valve bodies are available in six different designs and can be equipped with regulator spindles.

MAXIMATOR valves of the 65V series have a cold-machined stainless steel body. Valve bodies are available in six different designs and can be equipped with regulator spindles.

A special feature is the non-rotating stem which ensures a long life and thus a high reliability of the valve.

These MAXIMATOR high pressure valves with metal sealing have a high level of safety and reliability under adverse operating conditions. These valves may be employed both with gases and all fluids.

Their traceability is ensured through extensively documented data (batch number, max. pressure, material number, type designation).

Each high pressure valve of the MAXIMATOR series is completely equipped with gland and collar.

Technical data

Ball check valves
Body material316L (1.4404)
Stem material17-4PH (1.4542)
Medium
see Medium compatibility guide
Temperature-50°C to +230°C
SealPTFE + Carbon
Connection4HF, 6HF, 9HF
Orificeup to 0.078" (2mm)

Special features

  • High-quality valve body 1.4404 (316L)
  • Relief bore for absolute safety
  • Six different valve designs
  • Non-rotating stem

Special designs

  • Elongation for valve handles
  • Extreme temperatures
  • Special materials
TypeO.D. Tube inNameValve typeOrifice mm
2-Way-Angle-Valve1/465V4H082Regulating Stem1,6
1/465V4H072Standard Valve1,6
3/865V6H082Regulating Stem1,6
3/865V6H072Standard Valve1,6
9/1665V9H082Regulating Stem1,6
9/1665V9H072Standard Valve1,6
2-Way-Angle-Valve with replaceable Seat1/465V4H882Regulating Stem1,5
1/465V4H872Standard Valve1,5
3/865V6H882Regulating Stem1,5
3/865V6H872Standard Valve1,5
9/1665V9H882Regulating Stem1,5
9/1665V9H872Standard Valve2
2-Way-Straight-Valve1/465V4H081Regulating Stem1,6
1/465V4H071Standard Valve1,6
3/865V6H081Regulating Stem1,6
3/865V6H071Standard Valve1,6
9/1665V9H081Regulating Stem1,6
9/1665V9H071Standard Valve1,6
3-Way-1 on Pressure-Valve1/465V4H084Regulating Stem1,6
1/465V4H074Standard Valve1,6
3/865V6H084Regulating Stem1,6
3/865V6H074Standard Valve1,6
9/1665V9H084Regulating Stem1,6
9/1665V9H074Standard Valve1,6
3-Way-2 on Pressure-Valve1/465V4H083Regulating Stem1,6
1/465V4H073Standard Valve1,6
3/865V6H083Regulating Stem1,6
3/865V6H073Standard Valve1,6
9/1665V9H083Regulating Stem1,6
9/1665V9H073Standard Valve1,6
3-Way-2-Stem-Manifold-Valve1/465V4H085Regulating Stem1,6
1/465V4H075Standard Valve1,6
3/865V6H085Regulating Stem1,6
3/865V6H075Standard Valve1,6
9/1665V9H085Regulating Stem1,6
9/1665V9H075Standard Valve1,6
