VFT – Valves 22500 psi

  • MAXIMATOR valves of the 21V series have a cold-machined stainless steel body. Valve bodies are available in six different designs and can be equipped with regulating stem.
  • A special feature is the non-rotating stem which ensures a long life and thus a high reliability of the valve.

MAXIMATOR valves of the 21V series have a cold-machined stainless steel body. Valve bodies are available in six different designs and can be equipped with regulating stem.

A special feature is the non-rotating stem which ensures a long life and thus a high reliability of the valve. These MAXIMATOR high pressure valves with metal sealing have a high level of safety and reliability under adverse operating conditions.

These valves may be employed both with gases and all fluids. Their traceability is ensured through extensively documented data (batch number, max. pressure, material number, type designation).

Each high pressure valve of the MAXIMATOR series is completely equipped with gland and collar.

Technical data:

Body material
316L (1.4404)
Stem material17-4 PH (1.4542)
Mediumsee "Medium compatibilty guide"
Temperature-50ºC - +350ºC
Sealing PTFE + Carbon
Connection4MF, 6MF, 9MF, 12MF, 16MF
Orifice 0,11" - 0,56" (2,7 - 14,3mm)

Special features

  • High-quality valve body – 1.4404 (316 L)
  • Relief bore for absolute safety
  • Six different valve designs
  • Non-rotating stem

Special designs

  • Elongation for valve handles
  • Extreme temperatures
  • Special materials
TypeO.D. Tube inNameValve typeOrifice mm
2-Way-Angle-Valve1/421V4M082Regulating Stem2,7
1/421V4M072Standard Valve2,7
3/821V6M082Regulating Stem5,1
3/821V6M072Standard Valve5,1
9/1621V9M082Regulating Stem7,8
9/1621V9M072Standard Valve7,8
3/421V12M082Regulating Stem11,1
3/421V12M072Standard Valve11,1
121V16M082Regulating Stem14,3
121V16M072Standard Valve14,3
2-Way-Angle-Valve with replaceable Seat1/421V4M882Regulating Stem2,7
1/421V4M872Standard Valve2,7
3/821V6M882Regulating Stem5,1
3/821V6M872Standard Valve5,1
9/1621V9M882Regulating Stem7,8
9/1621V9M872Standard Valve7,8
3/421V12M882Regulating Stem11,1
3/421V12M872Standard Valve11,1
121V16M882Regulating Stem14,3
121V16M872Standard Valve14,3
2-Way-Straight-Valve1/421V4M081Regulating Stem2,7
1/421V4M071Standard Valve2,7
3/821V6M081Regulating Stem5,1
3/821V6M071Standard Valve5,1
9/1621V9M081Regulating Stem7,8
9/1621V9M071Standard Valve7,8
3/421V12M081Regulating Stem11,1
3/421V12M071Standard Valve11,1
121V16M081Regulating Stem14,3
121V16M071Standard Valve14,3
3-Way-1 on Pressure-Valve1/421V4M084Regulating Stem2,7
1/421V4M074Standard Valve2,7
3/821V6M084Regulating Stem5,1
3/821V6M074Standard Valve5,1
9/1621V9M084Regulating Stem7,8
9/1621V9M074Standard Valve7,8
3/421V12M084Regulating Stem11,1
3/421V12M074Standard Valve11,1
121V16M084Regulating Stem14,3
121V16M074Standard Valve14,3
3-Way-2 on Pressure-Valve1/421V4M083Regulating Stem2,7
1/421V4M073Standard Valve2,7
3/821V6M083Regulating Stem5,1
3/821V6M073Standard Valve5,1
9/1621V9M083Regulating Stem7,8
9/1621V9M073Standard Valve7,8
3/421V12M083Regulating Stem11,1
3/421V12M073Standard Valve11,1
121V16M083Regulating Stem14,3
121V16M073Standard Valve14,3
3-Way-2-Stem-Manifold-Valve1/421V4M085Regulating Stem2,7
1/421V4M075Standard Valve2,7
3/821V6M085Regulating Stem5,1
3/821V6M075Standard Valve5,1
9/1621V9M085Regulating Stem7,8
9/1621V9M075Standard Valve7,8
3/421V12M085Regulating Stem11,1
3/421V12M075Standard Valve11,1
121V16M085Regulating Stem14,3
121V16M075Standard Valve14,3
