VFT – Fittings 152000 psi

MAXIMATOR fittings and bolted unions of the 10,500 bar series are designed for simple and safe connection of HP pipes up to a max. pressure of 10,500 bar.

MAXIMATOR fittings and bolted unions of the 10,500 bar series are designed for simple and safe connection of HP pipes up to a max. pressure of 10,500 bar.

All bolted unions are fit for multiple use. Fittings are supplied complete with collars and glands.

Anti-vibration bolted unions may be used to attain permanent connections even under extreme mechanical loads.

MAXIMATOR fittings and bolted unions are compatible with HP systems made by other manufacturers.

Technical data

Body materialHP160
Collar material316L (1.4404)
Gland material
316L (1.4404)
Temperature-50°C to +150°C
Connection5UF
TypeO.D. Tube /inNameOrifice /mm
Bulkhead Coupling5/16152BF5U2,3
Collar5/16152C5U
Cross Connector5/16152X5U2,3
Elbow-Connector5/16152L5U2,3
Gland5/16152G5U
Plug5/16152P5U
Straight Coupling5/16152F5U2,3
Tee-Connector5/16152T5U2,3
Tube Cap5/16152TC5U
