VFT – Filters 22500 psi
- MAXIMATOR dual-disc line filters of the 1,550 bar series filter gases and fluids to a max. pressure of 1,550 bar.
- MAXIMATOR cup type filters of the 1,550 bar series filter solids from gases and fluids up to a max. pressure of 1,550 bar.
MAXIMATOR dual-disc line filters
MAXIMATOR dual-disc line filters of the 1,550 bar series filter gases and fluids to a max. pressure of 1,550 bar.
Thus, sensitive components are protected. Filter elements may be easily replaced on site.
Filters are supplied complete with collars and glands. The indicated micron size is ensured by structural measures.
Advantages
- Two step filtration
- Larger particles do not clog the fine filter (cascade filtration)
MAXIMATOR cup type filters
MAXIMATOR cup type filters of the 1,550 bar series filter solids from gases and fluids up to a max. pressure of 1,550 bar.
Thus, sensitive components are protected. Filter elements may be easily replaced on site.
Filters are supplied complete with collars and glands. The indicated micron size is ensured by structural measures.
Advantages
- Large filter surface
Technical data
| DUAL-DISC LINE FILTERS | CUP TYPE FILTERS | |
|---|---|---|
| Body material | 316L (1.4404) | 316L (1.4404) |
| Collar material | 316L (1.4404) | 316L (1.4404) |
| Gland material | 316L (1.4404) | 316L (1.4404) |
| Filter area | 0,25 in² (165mm²) | 0,82 in² (530mm²) @ 1/4" & 3/8" 1,55 in² (1000mm²) @ 9/16" 6,14 in² (3690 mm²) @ 3/4" & 1" |
| Temperature | -50ºC - +350ºC | -50ºC - +350ºC |
| Connection | 9MF | 4MF, 6MF, 9MF, 12MF, 16MF |
| Type | O.D. Tube /in | Name | Micron size /µm | Orifice /mm |
|---|---|---|---|---|
| Cup-Type Line Filter | 1/4 | 21CF4M-56 | 56 | 2,7 |
| 1/4 | 21CF4M-5 | 5 | 2,7 | |
| 1/4 | 21CF4M-30 | 30 | 2,7 | |
| 3/8 | 21CF6M-56 | 56 | 5,1 | |
| 3/8 | 21CF6M-5 | 5 | 5,1 | |
| 3/8 | 21CF6M-30 | 30 | 5,1 | |
| 9/16 | 21CF9M-56 | 56 | 7,8 | |
| 9/16 | 21CF9M-30 | 30 | 7,8 | |
| 9/16 | 21CF9M-5 | 5 | 7,8 | |
| 1 | 21CF16M-30 | 30 | 14,3 | |
| 1 | 21CF16M-56 | 56 | 14,3 | |
| 1 | 21CF16M-5 | 5 | 14,3 | |
| Dual-Disc Line Filter | 9/16 | 21DF9M-5/8 | 5/8 | 6,5 |
| 9/16 | 21DF9M-8/30 | 8/30 | 6,5 | |
| 9/16 | MLFX9900-30/56 | 30/56 | 6,5 |
